Universal 4-Sided Oven Door Seal (For Rounded Corners)

Product Description

Universal 4-Sided Oven Door Seal (For Rounded Corners)

If the oven door seal is faulty you could find that your food is not being cooked correctly and the control panel and its control knobs are melting.

This universal door seal is designed to fit most modern ovens that have a four-sided seal with round corners and a groove inside the cavity. It will effectively replace seals with curved corners. The seal attaches to the oven's body by a single hook in each corner.

Please make sure that there is a single hole in each corner of your oven. This will not fit ovens that have two holes in each corner. For oven seals with square corners see ES131929

Instructions:

• Measure the distance between the holes and make a note of the measurements.
• Cut the seal's top, bottom and sides to size using the supplied instructions.
• Lay the seal out ridge side up.
• Insert the barbed corner hooks into the slot of the seal making sure that the hook on the connector is facing down.
• Clip the corner hooks into the holes on the face of the oven cavity.



Specification:

• Silicon
• Length: 2m
• Width: 10mm
• Includes four rounded metal brackets that face inwards (for ovens with corners that are rounded)
• Allows the seal to be fitted in an arc around each corner
• Suitable for ovens that have a groove around the cavity, one hole in each corner and four-sides
• Please measure the perimeter of your current seal to ensure it is 2 metres or smaller

• Manufacturers’ names and numbers are used for reference purposes only. These parts are in no way associated with the initial manufacturers parts
